Breakmate Machine Manual (Parts & Service)- Price: $15.00 each Select your Manual Model. Coca-Cola Breakmate Machines. This is the machine for you if you love Coke products! According to marketing materials and the L2 Manual, the BreakMate had a number of features for it’s time with the system being called “compact and lightweight”. Coca-Cola Breakmate Machine. Sell - Rent - Service - Supply Personal single serve Coca-Cola machine. Make your break room as unique as your staff. Coca-Cola Breakmate is a great added benefit for supplying small offices or other commercial locations with fresh, cold, delicious soda.

  1. Breakmate Machine
  2. Breakmate Manual
  3. Breakmate Service Manual

WELCOME TO SODAMACHINEMANUALS.COM. UPDATED AUGUST, 2009. You have found the largest online source for Soda Machine Manuals, Brochures and Flyers. We have over 800 different machines and coolers represented on this web site from 1920's to Present (mostly 50's.

Accessorize Your Breakmate
All Paypal orders now include a flat $12 shipping charge.
Note some items include additional S&H due to insurance, size or weight.
Pricing is changing effective immediatly for most items due to lack of inventory.

Six Button Front Panel Expansion

The six button front panel expansion adds the options to dispense soda water only and to select drink size. Comes with your choice of 3 flavor stickers (please specify flavors in payment notes) and a new flavor card.

Six button front panel, New flavor card

$50.00


Drink Size Modification Jumpers

Two drink size modification jumpers are available for the Breakmate. One will force the Breakmate to dispense 10 ounce drinks only. The other jumper offered is an exclusive hack from Mr. Breakmate that will allow you to toggle between 6 and 10 ounce drinks (assuming you purchased the 6 button panel expansion above). The hacked jumper will turn your small drink into an 'Extra Large Drink' so you need to print out this little label to go over your 'small drink' label on the flavor card.

These jumpers do not work if you have a coin-op installed, since the jumpers attach to the control board on those same pins.

Size Modification Jumpers
$5.00, 10 ounce only


External CO2 Adapter

For those of you who can't get the special Breakmate CO2 bottles refilled locally, this adapter will let you connect the Breakmate directly to a standard CO2 bottle that you can get filled anywhere. In addition to a standard CO2 bottle, you must supply a CO2 regulator capable of reading up to 120 PSI. We include a brand new dual gauge high pressure CO2 regulator in our External CO2 Adapter KIT (below) along with all the other fittings you will need.

External CO2 Adapter Only
$69.00, For just the adapter & 10ft. hose


External CO2 Adapter KIT
$159.00 + $5 Additional Shipping
Same as above, but also includes the required 120 PSI regulator (new) and all fittings

Water Jug Attachment

If plumbing is not your cup of tea, or you simply can't run a water line to the Breakmate then the Water Jug attachment will solve all your troubles. This brand new attachment is actually a separate contained pumping system. It operates as needed (a.k.a. on demand) and easily connects to the back of the Breakmate where the water line normally would attach. The water jug used (not included) is a standard 3 or 5 gallon water cooler jug. For best flavor, it is recommended that you fill the water jug with filtered water or get it refilled wherever you purchased the jug.

The Water Jug attachment comes with a 1 year manufactures warranty.

Water Jug Attachment, New

$$175, plus $6 additional shipping


Watermate Attachment

The Watermate attachment is the original accessory for the Breakmate that eliminated the need for a permanent water line installation. The Watermate has an internal pump and a reservoir that holds a little more than a gallon of water.

For best flavor, it is recommended that you fill the reservoir with filtered water (the gallons from the supermarket work well). Installing the Watermate will depend on whether or not you Breakmate has a black plug with a flap over it on the back left side. If so, then installation is as easy as plugging it in and hooking up the water line. Otherwise you will need to run three wires from the Watermate into the Breakmate for power. This procedure is not complicated and we can guide you through it. The Water Jug Attachment (above) is recommended for easiest install.

Used Watermate Attachment, Limited Availability

$ SOLD OUT


BA-320 Coin-op Attachment

The Coin-op attachment shown here is the top of the line BA-320. It offers multiple coin support with easily programmable amounts in 5 cent increments. The BA-320 also supports two drink sizes and prices. Installation is strait forward and requires minimal disassembly of the Breakmate. The procedure is not complicated and we can guide you through it if necessary. Here is a link to the install manual in compressed .zip format.

Other Coin-ops that have fewer functions were available at reduced cost (but we're sold out of those models).

BA-320 Coin-op Attachment, NEW in original box

$130.00 + $15 Additional Shipping

Breakmate Manual

BA-300 Coin-op Attachment

The Coin-op attachment shown here is the BA-300. It offers multiple coin support with easily programmable amounts in 5 cent increments. The BA-300 also supports two drink sizes via a toggle switch in the coin collection area. Installation is strait forward and requires minimal disassembly of the Breakmate. The procedure is not complicated and we can guide you through it if necessary. Here is a link to the programming manual in .bmp format. The install manual is the same for the BA-320, see above.

Other Coin-ops that have fewer functions are available at reduced cost.

BA-300 Coin-op Attachment, Used

SOLD OUT SORRY

Breakmate Machine


Smart Board ECU with Front Panel

Smart Board ECU Unit.
The smartboard has several additional functions over the standard ECU. These include low/sold out syrup indicators, water-out, CO2 out, night security lockout and memory to retain settings through power outages.
The syrup low/sold out is all adjustable and basically counts how many drinks dispensed and will flash a light next to the flavor should it reach some set threshold.
The water-out requires an internal water flow sensor, which is rather rare (at least for the machines I've seen).
The smartboards are no longer available from Coke, so supply is very limited.
Most smart boards need a different front panel kit with either 3, 5 or 6 buttons. The correct front panel is included with the kit sold here. If you need just the ECU, then check out the parts page.

The first option available is the 3 button front panel kit which does not include size selection or the soda-water-only button.

Smart Board ECU kit with 3 button panel, New

$249.00 + $4 Additional Shipping

The second option available is the 5 button front panel kit which includes 3 size selection (3/6/9 ounce) and the soda-water-only button.

Smart Board ECU kit with 5 button panel, New

$265.00 + $4 Additional Shipping


Internal Paintball Tank Apparatus

This accessory was requested by several of my customers who could not have ANYTHING external to the machine, inlcuding the external CO2 adapter kit. This system uses standard paintball tanks for CO2 supply. The tanks are small enough to fit inside the machine without restricting the syrup door from closing.
The tanks can be filled anywhere paintball tanks are filled. Make sure you let them know you are using it for food.

This system is not for everyone as it is a little dangerous if mishandled. This is also a specialty item made to order, so expect at least a week for shipment, perhaps more if parts aren't on hand.

For more information on this system, click here. One slim 9 ounce CO2 tank is included. Others can be used but may interfear with the black clamping handle.

To be used at your own risk, no warranty expressed or implied!

Internal Paintball Tank Adapter

No longer for sale, sorry. Check out the link above and you can probably piece one together yourself.


Home | Breakmate Types | Basics | Syrups & CO2 | Parts & Service | Accessories | Order | Testimonials | Shipping | Links |

If you have any questions or suggestions regarding this site,
please e-mail the Webmaster. For Product Help/Info please email Customer Service.
© copyright 2021 Mr. Breakmate.com, a division of Ty's Supplies, LLC. All Rights Reserved.

Where can I find the official BreakMate Level II Service Manual?

The official Coca Cola BreakMate Level 2 Service Manual can be found here on Breakmatesource.com, in our interactive Service Manual guide.

Breakmate manual

Is available on this page, BreakMate Service Manual

BreakMate FAQ: How to Fill Syrup Containers / How to Reuse Syrup Containers?

[permalink id=340]

New to the Coke BreakMate machine? Wondering how Coca Cola BreakMate fans refill the soda machine?

In the past, Coca Cola used to sell specific BreakMate syrup containers that were non-refillable. Nowadays, Coke no longer manufacturers these special syrup bottles, so you need to reuse your own bottles.

In this video, we show you how to refill your Coke BreakMate Syrup with Bag-In-Box (BIB) syrups.

BreakMate FAQ: Are parts dishwasher safe?

[permalink id=333]
It seems like a no-brainer, right? BreakMate parts need to be cleaned and you have a dishwasher – so why not dish wash your parts in order to sterilize them??
The common consensus is tonever wash any BreakMate parts in a dishwasher. The main reason(s) for this are age and rarity.

  • Age
    • BreakMate parts are getting quite old. At this point, some could be upwards or close to 20 years old. The plastic pieces have undoubtedly become brittle over time and even if they haven’t, running a 15+ or 20+ year old part through a high-pressure, high-temperature through a dishwasher is just a bad idea.
  • Rarity
    • Many BreakMate parts are becoming much harder to find. So, if you were to break a part – even with standard use – getting replacement parts is becoming more difficult with each passing day. Why would you risk a higher chance of breakage using a dishwasher to clean your parts?

The recommended way to clean your BreakMate parts is with a Vinegar solution, or a diluted bleach solution. Then you should use a toothbrush or similar tool while handwashing in this solutions to clean/disinfect your parts. If you want to clean out the internal lines, you’ll need to run this solution into and then out of the BreakMate. Usually 1-2 passes (fill up the carbonator completely and then empty completely) with this solution and then 2-3 “clean water” passes (again, fill up completely, drain completely) is good enough to clean the internal lines and compartments.

BreakMate FAQ: How long do Syrups last?

[permalink id=330]
According to most, all regular Bag-In-Box Syrups generally have a “best buy” date. However, that date is really more of a suggestion. After the “best buy” date has passed, it is more than likely that the taste may begin to suffer, especially as the best buy date gets older. That being said, the syrups are still more than likely good to use.

The exception to this rule is diet syrups. Those generally have a shorter shelf-life due to using other sweeteners and chemical preservatives.

Search “Syrup Expiration Dates” or “Bag In Box Syrup Best Buy Date” to see other sites mentioning/answering this question:

BreakMate FAQ: First Time Startup – Water Into BreakMate

[permalink id=311]
A very important step during initial startup of a BreakMate is getting the water into the system. Once you have the system hooked up to your water source, you want to make sure that the carbonator is empty and not pressurized with CO2. To empty the carbonator of CO2, remove your CO2 tank (or connector, if using an external CO2 source) :

  • press and hold the red release button, located to the left of the CO2 cartridge lock (see image).
    • Continue to hold the button until there is no more “Air” coming out of the unit.
  • After that’s done, turn your machine on and let it fill with water.
  • After the water has fully filled the unit and the pump turns off, then you may re-attach your CO2 tank/adapter.

If you try to fill your BreakMate with water for the first time and water does not flow, generally it is because the system still has CO2 in the carbonator.

If you’ve emptied the carbonator and there is zero pressure if water still does not flow, you may have a bad pump or inlet valve.

Failure to empty the pressure in the system before filling at least may cause the system not to fill. If you’re using an external pump and/or if your lines are not correct, you could potentially blow the line out or damage the external pump.

BreakMate FAQ: How Do I Adjust the Taste / Mixture of Soda Syrup to Soda Water

Breakmate Manual

[permalink id=304]
The BreakMate dosers output a specific “shot” of Syrup for each size cup that is selected. For example, a 10oz glass of soda from a Coke BreakMate machine will operate the Doser 3 times throughout the soda-water dispensing time.

Ultimately, there is no way to adjust the amount of Syrup that is dispensed per cup size, however, you can adjust the amount of soda-water that is dispensed in order to achieve a 5:1 (5 to 1) soda-water to syrup mixture, which is recommended by almost all major-label syrup manufacturers.

If you need to adjust the water level, turn the adjustment screw a very little bit at a time until your water level is accurate.

Breakmate Service Manual

Breakmate manual

How do you tell if your water level is accurate?

Remove the mixing channel and remove your syrups and dosers. With a graduated cylinder or some other ‘catch cup’ underneath the output valve, select a soda to dispense. You’ll need to measure the amount of liquid that has been obtained.

Now for the slightly-more-tricky measuring technique. For this step. Add in the left-most Syrup container and doser, but keep the mixing channel out. With one cup under the output valve and another cup or graduated cylinder under the far-left syrup doser, select the 3rd button down. You should get the same amount of water into your cup under the output valve, and you should receive a separate cup of syrup.

Measure your syrup by itself. If the difference between syrup and soda-water is not 5:1, adjust the output valve screw (again, very slowly) until you’ve reached the correct mixture. Of course, this does not have to be completely precise and you can also adjust the water level to your preference as well.

BreakMate FAQ: User How-To: How Do I Get A Soda? (How do I operate the machine)

[permalink id=232]
Assuming that you have successfully set up your BreakMate machine (see our article on how to do that, too), to get a soda:

  1. Place an appropriately-sized cup above the “cup indicator” on the left side of the machine (see image below):
  2. If applicable, select your drink/cup size
  3. If applicable, insert money into the coin mechanism
  4. Press the button for the corresponding soda you would like
    • You will hear the machine make some noise – sometimes loudly (by today’s standards).
    • Wait until the machine has FULLY stopped dispensing soda and then wait another 5-10 seconds. The mixing channel takes a few moments to fully clear and stop dripping once your soda has been dispensed.
  5. After a few moments and the excess drips have stopped, you may remove your beverage and enjoy.

Step 1 Image:

All Steps: How-To Video:

*I should note that the video below shows a 6-button (rare) BreakMate machine. I’ll shoot a new video with a 3-button (standard) machine shortly.

What are (were) the BreakMate selling features?

[permalink id=231]
According to marketing materials and the L2 Manual, the BreakMate had a number of features for it’s time with the system being called “compact and lightweight” (remember, this was 1980s-1990s). Other features included:

Breakmate
  • a Plug-In Syrup System (although, now discontinued, you must refill your own syrup bottles/cartridges)
  • a Plug-In CO2 Cylinder/Tank (again, now most CO2 suppliers no longer have the refill adapter – most people will convert their systems to use regular CO2 tanks (see our how-to, coming soon)
  • a minature high pressure water pump
  • a stainless steel carbonator with removable top
  • pre-set syrup valves (no adjustments necessary)
  • electronic controls with built-in diagnostics system
  • plumbed, filtered water supply for consistent high-quality drink
  • optional coin-mechanism for vending – that can also be set to vend for free
  • optional advanced coin-mechanism allowing for pricing to be altered from 5 cents to $1.55
  • optional 6.5 or 10oz drink size / cup size (standard is 3.5oz and 6.5oz)
  • an internal leak sensor and automatic water shut-off
  • optional “WaterMate” attachment – so you don’t need to connect the system directly to a water line
Service

What is a BreakMate Machine?

[permalink id=227]
A Coke BreakMate machine, or Coca-Cola Breakmate, also known as a Pomino, MiniPom, or Siemens GA Soda-Fountain, is a “compact, easy-to-use, and highly reliable carbonated soft drink dispensing system, developed and produced by Siemens exclusively for the products of The Coca-Cola Company”. (BreakMate L2 Manual)

Although a few different model numbers exist, the two most-popular in the US are the Siemens GA 3000 and GA 3450.

A standard BreakMate machine with no attachments looks like this:
